Category：Face Recognition Terminal
Product ID：
Views：3052
Product Introduction：
Details
The product is based on 200W RGB, 200W IR binocular camera, supports WIFI + 10 / 100M network and rich peripheral security interface, to meet the needs of user access control, can realize personnel authentication, personnel entry and exit management and attendance management.
The products are widely applicable to office buildings, office areas, hotels, schools, shopping malls,communities, public services, stations and scenic spot pavilions and other traffic scenarios that need to be used, which is conducive to the realization of intelligent safety control.
Thermal Face Recognition Device Specification Performance
F6 Facial Recognition Device Datasheet.en
Access control face recognition time attendance system
Product module
F6
Product
features
major function
Access control, attendance, access gate
Usage environment
Indoor, outdoor
4/16
resolution ratio
200 megapixels
200 megapixels
Vertical wide Angle
65°
65°
Horizontal wide Angle
40°
40°
White light supplement
support
Infrared light supplement
support
Core
parameters
system
android 11.0
CPU
RK3566 4x ARM⑧ Cortex TM A55up to1.8GHz
SC
Memory 2G,storage 8G
human-computer interaction
display screen
8-inch, Full View,170°IPS LCD, resolution 800* 1280
touch screen
support
Human temperature measurement module [Optional]
Test accuracy: 0.1 ℃
test error:<±0.5℃
Temperature measurement distance: the recommended use distance is 50cm
Operating temperature: 15℃～40℃
communication model
Ethernet
10/100Mbps Ethernet
WIFI
Compliance with the IEEE802.11b/g/n standard (2.4G)
4G[Optional]
CAT1, domestic full Net
RM
human face
support
IC card[optional]
support
certificate of identification
Network ID card [Optional]
Local ID card needs external connection [optional]
Interface
data interface
USB 2.0*2
electric relay
*1
gorge line
RS4851
Wigan
The 26bit/ 34bit protocol
Go out switch
*1 [Expandable]
Fire linkage
*1 [Expandable]
key
Upgrade key
Source
adapter
DC12V/2A power supply
Environmental requirement
working temperature
-20℃～60℃
Operating humidity
20%～90%(No condensation water drop state)
static electricity ESD
IEC61000-4-2,LEVEL3
levels of protection
IP65
