LV3000H OEM Scan Engine Passport Reader

Category:Fixed Mount Scanner

Product ID:LV3000H

Views:5283

Product Introduction:Rakinda's latest technology gives the scan engine an edge with unrivaled decoding capabilities on 1D & 2D barcodes.




Inquiry Now

Details

It can read high-precision barcodes, and it has advantages to read high passwords; the working temperature is high, and it can be read at Work normally under extreme temperatures;Portable passport MRZ reader ID card OCR 1D QR barcode scanner for airport or hotel.

QR Code Scanner Kiosk Features:

* Infrared/light sensing dual trigger

Megapixel camera

* It can quickly read all kinds of one-dimensional/two-dimensional barcodes and large-data screen two-dimensional barcodes with various films.
* Full code support, customizable
* Automatic exposure control, the sensor on the device can automatically adjust the brightness of the fill light according to the intensity of the light reflected by the barcode
* IP54 protection level
* 1.5m drop resistance


Parameters of Turnstile Barcode Scanner

LV3000H Datasheet-EN

Performance

Image Sensor

1280*800 CMOS

Illumination Aiming

Red LED/Laser Aiming

Symbologies

2D

PDF417, QR Code, Data Matrix, AZTEC, CSC, Maxicode, Micro QR, Micro PDF417, GM, Code One, ect.

1D

EAN-13, EAN-8, UPC-A, UPC-E, Code 128, Code 39, Codabar, UCC/EAN 128, RSS, ITF, ITF-14, ITF6, Standard 25, Matrix 25, COOP 25, Industrial 25, MSI Plessey, Code 11, Code 93, Code 49, Code 16K, etc.

 Resolution

>=3 mil

Typical Depth of Foeld

 EAN-13

55-360mm(13mil)

Code 39

70-180mm(5mil)

PDF417

55-160mm(6.7mil)

Data Matrix

50-170mm(10mil)

QR Code

40-210mm(15mil)

Scan Mode

Sense mode, Continuous mode, Level mode, Pulse mode

Scan Angle

Roll:360d, Pitch:±55°, Skew:±55°

Field of View

Horizontal 51°, Vertical 32°

 Min Symbol Contrast

25%

 Mechanical Electric

 Interface

RS-232, USB

Dimensions

41.2(W) x49.2(D)x 24.15(H)

Weigh

75g

Notification

Beep, LED indicator

Rated Power Consumption

1622mW(typical)

Operating Voltage

 5VDC±-5%

Current SVDC

Operating

276.8mA(typical), 322.7mA(max.)

Standby

83.3mA

Environmental

Operating Temperature

 -20℃ to 60℃(-4℉ to140℉)

 Storage Temperature

 -40℃ to 70℃ (-40℉ to 158℉)

 Humidity

5% to 95% (non-condensing)

 ESD

± 14kV (air discharge), ±8kV (direct discharge)

 Drop

1.5m

Sealing

IP68

Certifications

FCC Part1S Class& CE EMC Class B, RoHS, IEC60825, IEC62471, KC

Environmental

Cable

  USB

Used to connect to a host device

RS-232

Used to connect to a host device

Power Adapter

DC5V adapter to power with RS-232 cable
